Specifications
Frame
Wide, 6061 T4-T6 alloy, 120mm travel, Bosch PowerTube exclusive battery integration (horizontal), 12x148mm, Boost, motor cover with cooling fins & chain guide
Fork
Marzocchi, Bomber Z2, RAIL, compression sweep adjust, 130mm travel, 15x110mm, Boost, 44mm offset, mini-fender compatible
Shock
Moustache, Magic Grip Control 120, specific Air Shock with 2-position platform and dynamic control of rebound, Trunion mount, build-in 165x45mm, 120mm travel
Motor
Bosch, Performance Line CX, 250W, Smart System, 85Nm
Battery
Bosch, PowerTube 625Wh, horizontal, Smart System
Charger
Bosch, 4Ah
Display
Bosch, Kiox 300, Smart System, compact, color screen, customizable screens, Lock function (optional), « Walk assist », LED Remote bluetooth Modes: Eco, Tour+, eMTB, Turbo
Rear Derailleur
Shimano, XT, RD-M8100-SGS, 12-speed ; WI-BO035
Cassette
Sunrace, CSMZ8, 12-speed, 11-51T
Chain
Shimano, CN-M6100, 12-speed, 120 links
Shifter
Shimano, Deore, SL-M6100, 12-speed
Cranks
Moustache, forged aluminium, 165mm
Brakes
Shimano, MT420, hydraulic disc, 4 pistons
Hubs
Front: Moustache, 28H, 15x110mm, thru axle // Rear: Moustache, 28H, 12x148mm, thru axle
Rims
Moustache, asymmetric, alloy 6061E, welded, double wall, 28 holes, 27.5", internal width 35mm, mounted with Tubeless valves & flap
Tyres
Maxxis, Rekon, 27.5x2.80
Saddle
Selle Royal, Essenza Moderate Men
Seatpost
EXA, 900i, dropper-post w/remote lever, 31.6mm
Handlebar
Moustache, alloy, 740mm, 15mm rise, 9° backsweep, 5° upsweep
Stem
Moustache, 3D forged Aluminum, 60mm
Grips
SB3, Ergonomic
Lock
- / Bosch Connect Module (BCM) compatible, with eBike Alarm function
Sizes
S (1,54 -1,69m) M (1,66 - 1,81m) L (1,78 - 1,93m) XL (1,90 - 2,05m)
Weight
24,4 kg
