Electric Bike Specifications
Speeds
1 x 14
Weight
38.77 kg (85.5 lb)
Gear Inches
18" - 96" (1.45 - 7.64 m)
Folding Size
185 × 46 × 88 cm (72.8 × 18.1 × 34.6 in)
Folding Time
5 seconds
Frame Sizes
One size
Distance: Seatpost to Handlebar
49 - 59 cm (19.3 - 23.2 in)
Distance: Saddle to Pedal:
69 - 105 cm (27.2 - 41.3 in)
Suggested Rider Height
153 - 200 cm (60.2 - 78.7 in)
Max Gross Vehicle Weight
210 kg (463 lb)
Max Load Weight
210 kg (463 lb)
Max Rider Weight
130 kg (286.6 lb)
Frame
Tern GSD, 6061-AL, patented MultiTruss design, DIN 79010 certified: 210 kg
Fork
Suntour custom for Tern, 1.5" tapered Chromoly steerer, 34 mm stanchions, Thru-axle, DIN 79010 certified: 210 kg
Handlepost
Tern Physis 3D, 3D forged, 5 patented technologies, 12°, 290 mm
Stem
Tern Andros, adjustable, forged construction, patented technology
Headset
Tern Flux Pro Taper by FSA, 1.5", angular contact bearings, Physis integrated
Handlebar
Tern Sweep, 6061-AL, Tern Andros adapted
Grips/Bar Tape
Ergon
Saddle
Tern GSD by Velo
Seatpost
Tern VLT (Very Large Telescope) with Cane Creek suspension and LightAction levers
Seatpost Clamp
Tern Collar
Front Brake
Magura MT-C ABS, 4-piston hydraulic disc, 203 mm rotor
Rear Brake
Magura MT-C ABS, 4-piston hydraulic disc, 203 mm rotor
Brake Levers
Magura MT-C e-stop, hydraulic, with brake light sensor
Brake Cable & Housing
Magura ABS, hydraulic
Front Wheel
Tern Atlas, heavy duty cargo wheel
Rear Wheel
Tern Atlas, heavy duty cargo wheel
Front Hub
Tern Atlas, Cooling Fins, Boost Thru-Axle, sealed cartridge bearings
Rear Hub
Rohloff E14, 526% range, Boost
Spokes & Nipples
Stainless steel
Rims
Tern Atlas, ultra wide 36 mm, dual reinforced joint
Tyres
Schwalbe Pick-Up, cargo-optimized, Super Defense puncture protection, Reflex
Shifter(s)
Rohloff E14, e-shift 14 spd
Crankset
Tern GSD, Gates CDX CNC machined beltring
Cassette/Freewheel
Gates CDX, precision CNC machined cog
Bottom Bracket
Motor integrated
Chain
Gates Carbon Drive CDX belt
Pedals
Urban with non-slip surface, sealed bearings
Shifter Cable & Housing
Rohloff E14, e-shift
Motor
Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
Battery
Bosch 800 PowerPack, Fast Swap, Dual Battery bays, optional 2 x 800 Wh max capacity
Display
Bosch Kiox 300 w/ LED remote, connectivity with Bosch eBike Flow IOS/Android app, electronic bike lock, Rohloff integrated shifting w/ auto downshift
Range
800 Wh: 67-144 km (42-89 mi); 1600 Wh: 134-288 km (83-179 mi)
Charger
220V, 4A (EU); 100-240V, 4A (US)
Connect Module
Bosch Connect Module with GPS/GSM connectivity & anti-theft alarm when subscribed to Flow+; free 12-month trial upon activation
Anti-Lock Braking System
Bosch Anti-Lock Braking System, Gen 2
Bell
Pitch Plus, brass
Chainguard
Tern GSD, full chain cover
Kickstand
Atlas Lockstand Gen 2, AutoLock w/ remote unlock, patented technology
Luggage Socket
Combo Mount
Front Light
Ignis Headlight, Hi/Lo beams, 700 lumens
Rear Light
RearStop Brake Light, Always on
Fenders
F: Aluminum R: GSD wheel guard
Rack(s)
Atlas G, 100 kg (220 lb) capacity
Frame Lock
ABUS or AXA, keyed-alike with Bosch battery
On-board Charging
USB-C, 5V/2.4A, 12W ma
